KRAFTWERK-10 AC Filter

The Kraftwerk (German for Electric Power Plant)  was conceived as a development of our 20 years old SILK project. We kept the good features like unrestricted, open sound, more analog style of presentation, better soundstage, easier to follow musical threads, darker background etc. We added 4 more filtered outputs and 2 unfiltered for the monoblocks. Another new feature is a DC blocker available for 4 filtered and 2 unfiltered outputs. We also added Voltmeter, Ampmeter, and much bigger chassis.

The electrical design is based on the Lukasz Fikus' Polytechnic studies diploma, where the AC and RFI/EMI influence on electronics was the subject. The SILK also was the fruit of frustration with the way other AC devices influence the sound. Namely, we believe that separation transformer based conditioners, AC regenerator conditioners, and deep filter conditioners make sound lifeless and uninvolving. We tried to design a filter that makes music actually MORE BEAUTIFUL !


What is MOST IMPORTANT is not to spoil the dynamics, live type of sound. Not choke the amplifier power and drive.

The main difference between Silk and Kraftwerk are: Silk is 4 outlets, Kraftwerk has 8+2 = 10 outlets.

the Kraftwerk is configurable as European -  SCHUKO , British UK plug and USA, no other outlets are available. We can mix outlets on one unit - depending what cables you have or what cables are easiest to buy in your region. (the wall is one cable anyway)
Kraftwerk also has voltage meter and amprerage  meter.
Kraftwerk accepts C19 AC plug cable only as an input. We supply the C19 cable if needed.

Silk was a filter only, in addition to filtering - Kraftwerk provides surge protrection, over-voltage protection, lightning protection and DC blocking.


MAIN PARAMETERS:
Dimensions:

440mm [W] x 505 mm [D] x 180 mm [H]

Weight 10kg (net)

Copper version weight 11kg

Number of individually filtered outlets: 8

Number of non-filtered outlets 2 with DC blocking

DC blocked are 4 of the 8 filtered outputs and both unfiltered outputs

Max current per each filtered output: 10A or 2300 W
Max current per each unfiltered output: 10A or 2300 W
Max summary load current: 16A or 2,3 kW

No fuses, no switches.

DISCONTINUED:  SILK   AC power filter

The SILK was conceived as an “extension” of Lukasz Fikus' Polytechnic studies diploma, where the AC and RFI/EMI influence on electronics was the subject. The SILK also was the fruit of frustration with the way other AC devices influence the sound. Namely, we believe that separation transformer based conditioners, AC regenerator conditioners, and deep filter conditioners make sound lifeless and uninvolving. We tried to design a filter that makes music actually MORE BEAUTIFUL:


What is MOST IMPORTANT is not to spoil the dynamics, live type of sound. Not choke the amplifier power and drive.

The main difference between Silk and Kraftwerk are: Silk is 4 outlets, Kraftwerk has 8+2 = 10 outlets.

Silk can have USA and GB and Schuko outlets, the Kraftwerk is ONLY SCHUKO.
Kraftwerk also has voltage meter and amprerage  meter.




MAIN PARAMETERS:
Dimensions:

440mm [W] x 320 mm [D] x 140 mm [H]

Weight 6kg (net)

Number of individually filtered outlets: 4

Number of non-filtered outlets 0

Max current per each filtered output: 15A or 3000 W
Max summary load current: 15A or 3 kW

No fuses, no switches.

Silk - Front

Silk - Front

Lampizato Silk web

Lampizato Silk web

SILK REAR

SILK REAR

SILK REAR CABLE

SILK REAR CABLE

Silk - two colors

Silk - two colors

Silk Silver

Silk Silver

REVIEWS

"I purchased a Silk Silver. It is without a doubt one of the best available."
